1 HP Submersible Cutter Pump – 10 m³/h, 10 m Head
The 1 HP Submersible Cutter Pump is designed for drainage and pumping applications involving dirty water, domestic wastewater, sewage and other liquids containing suitable soft solids and particles. It has a 0.75 kW / 1 HP motor, maximum flow of 10 m³/h, maximum head of 10 metres, and a 50 mm outlet.
The pump is suitable for applications in industry, agriculture, mining, construction, municipal services and environmental protection, as well as agricultural irrigation, drainage, pool silt cleaning and construction-site pumping.
Performance Curve
Applications
- Sewage pumping
- Domestic wastewater
- Dirty water drainage
- Muddy water pumping
- Agricultural drainage
- Agricultural irrigation
- Construction-site drainage
- Municipal applications
- Environmental protection
- Pool silt cleaning
Operating Conditions
| Parameter | Specification |
|---|---|
| Liquid Temperature | 0°C to +40°C |
| Ambient Temperature | 0°C to +40°C |
| Maximum Working Pressure | 6 bar |
| Pumped Liquid pH | 4–10 |
| Immersion Depth | 0.5–5 m |
| Sand Content | ≤ 2.5% |
| Suspended Solids | ≤ 5 mm |
Construction
| Component | Material / Specification |
|---|---|
| Pump Body | Cast Iron |
| Impeller | Cast Iron |
| Outlet | Cast Iron |
| Motor Case | SS304 |
| Motor Winding | 100% Copper Wire |
| Bearing | C&U |
| Shaft | SS304 Welding |
| Thermal Protection | Thermal Overload Protector |
| Insulation Class | B |
| Protection Rating | IP68 |
| Duty | Continuous |
Important Selection Information
Check the required flow, total head, outlet size, immersion depth, liquid pH and solids content before selecting the pump. The catalogue specifies a maximum suspended-solids size of 5 mm, sand content of ≤2.5%, and immersion depth of 0.5–5 m.
