AOD PUMPS

In AOD PUMPS ( Air Operated Double Diaphragm ) Industry, Fluimac a renowned brand with over 13 years of experience that made in italy, offers high-quality, reliable, and durable Pumps designed for a wide range of applications. These pumps are available in a versatile range of 4LPM to 1000LPM, making them suitable for various industrial and commercial needs. As the authorized dealers for Sri Lanka, we provide these exceptional pumps, which come with a one-year warranty, ensuring peace of mind and long-term performance.

EMAIL : [email protected]

HOTLINE : 077 650 0088

P4 Phoenix Series AOD Pumps

Fluid connections: 1/4” BSPP
Air connection: 1/8″ BSPP
Max. Flow rate: 4 lt/min
Max air pressure: 6 bar
Max delivery head: 60 m
Max Suction Lift Dry: 3 m
Max Solid passing: 2 mm
Noise level: 62 dB
Max Viscosity: 5.000 cps
Material: PP, PVDF+CF and POMc

P8 Phoenix Series AOD Pumps

Fluid connections: 1/4” BSPP
Air connection: 1/8″ BSPP
Max. Flow rate: 7 lt/min
Max air pressure: 6 bar
Max delivery head: 60 m
Max Suction Lift Dry: 3 m
Max Solid passing: 2 mm
Noise level: 62 dB
Max Viscosity: 5.000 cps
Material: PP, PVDF+CF and POMc

P20 Phoenix Series AOD Pumps

Fluid connections: 3/8” BSPP
Air connection: 1/4″ BSPP
Max. Flow rate: 20 lt/min
Max air pressure: 7 bar
Max delivery head: 70 m
Max Suction Lift Dry: 5 m
Max Solid passing: 2,5 mm
Noise level: 65 dB
Max Viscosity: 10.000 cps
Material: PP, PVDF+CF, POMc and SS

P35 Phoenix Series AOD Pumps

Fluid connections: 1/2” BSPP
Air connection: 1/4″ BSPP
Max. Flow rate: 35 lt/min
Max air pressure: 7 bar
Max delivery head: 70 m
Max Suction Lift Dry: 5 m
Max Solid passing: 3 mm
Noise level: 65 dB
Max Viscosity: 15.000 cps
Material: PP, PVDF+CF, ALU and SS

P55 Phoenix Series AOD Pumps

Fluid connections: 1/2” BSPP
Air connection: 1/4″ BSPP
Max. Flow rate: 55 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 3,5 mm
Noise level: 70 dB
Max Viscosity: 15.000 cps
Material: PP, PVDF+CF, ALU e SS

P60 Phoenix Series AOD Pumps

Fluid connections: 1/2” BSPP
Air connection: 1/4″ BSPP
Max. Flow rate: 65 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 3,5 mm
Noise level: 72 dB
Max Viscosity: 20.000 cps
Material: PP, PVDF+CF, ALU and SS

P90 Phoenix Series AOD Pumps

Fluid connections: 3/4” BSPP
Air connection: 3/8″ BSPP
Max. Flow rate: 100 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 4 mm
Noise level: 72 dB
Max Viscosity: 25.000 cps
Material: PP, PVDF+CF, ALU and SS

P120 Phoenix Series AOD Pumps

Fluid connections: 1” BSPP
Air connection: 3/8″ BSPP
Max. Flow rate: 120 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 4 mm
Noise level: 72 dB
Max Viscosity: 25.000 cps
Material: PP, PVDF+CF, ALU e SS

P170 Phoenix Series AOD Pumps

Fluid connections: 1” BSPP-DN25
Air connection: 1/2″ BSPP
Max. Flow rate: 170 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 7,5 mm
Noise level: 75 dB
Max Viscosity: 35.000 cps
Material: PP, PVDF+CF, ALU (P 160) and SS

P252 Phoenix Series AOD Pumps

Fluid connections: 1”1/4 BSPP
Air connection: 1/2″ BSPP
Max. Flow rate: 250 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 7,5 mm
Noise level: 75 dB
Max Viscosity: 35.000 cps
Material: PP, PVDF+CF, ALU (P 250) and SS

P400 Phoenix Series AOD Pumps

Fluid connections: 1”1/2 BSPP-DN 40
Air connection: 1/2″ BSPP
Max. Flow rate: 380 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 8 mm
Noise level: 78 dB
Max Viscosity: 40.000 cps
Material: PP, PVDF+CF, ALU and SS

P700 Phoenix Series AOD Pumps

Fluid connections: 2” BSPP-DN 50
Air connection: 3/4″ BSPP
Max. Flow rate: 700 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 8,5 mm
Noise level: 78 dB
Max Viscosity: 50.000 cps
Material: PP, PVDF+CF, ALU and SS

P1000 Phoenix Series AOD Pumps

Fluid connections: 3” BSPP-DN 80
Air connection: 3/4″ BSPP
Max. Flow rate: 1050 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Solid passing: 12 mm
Noise level: 82 dB
Max Viscosity: 55.000 cps
Material: PP, PVDF+CF, ALU e SS
